L-Handle Ball Lock Pin Double Acting Positive Locking Pin

HKAA Double Acting Ring Handle Pins are ideal for quick insertion and removal and are activated by push or pull motion. Their ring handle configuration is designed for applications that require a small clearance area around the pin. The stainless steel construction and smart engineering of our Double Acting L-Handle Quick-Release Pins resist corrosion in harsh environments. Experience quick, easy positive engagement and high holding strengths for applications requiring frequent, repetitive use.

Material:

Handle: 303 Stainless Steel

Button: 303 Stainless Steel

Pin Body: Heat Treated 17-4 PH Stainless Steel

SPECS: MS17990 & NAS1353-NAS1366

Meets or exceeds NASM 23460 specifications

Includes split ring for easy attachment of an optional lanyard

May be ordered with (4) locking balls for additional locking element tensile strength.

Special materials, grip length, and longer “C” dimensions upon request.

Inquiry

Write a Review

Product Details

L Handle Pin 4

L Handle Pin 5

L Handle Pin 6

Product Description

These positive acting pins find widespread application in scenarios necessitating frequent assembly and disassembly and are used as alignment pins. They present an efficient and dependable solution for effectively securing components together, enhancing stability, and streamlining assembly processes. The compact handle size is particularly advantageous in situations where a T or L handle, also provided by HKAA, may not be the ideal choice.

--Double acting pins are activated by push and pull motion.Push/pull mechanism releases detent balls in any direction.

--Provide safety, dependability, and ultimate ease and speed of removal,"Push" button for easy insertion; "pull" handle for easy release

--All stainless steel construction provides additional corrosion resistance.

--Shank is made from high strength stainless steel 17-4 PH heat treated.

--Includes hole and split ring for easy attachment of optional lanyard.

--Customization is available.Choose from multiple handle styles, material constructions.

--Available with two or four detent-ball construction, different materials

--Approved on the QPL for NAS and NASM standards,Meets or exceeds MS17988, MS17989, MS17990, NASM 23460 specification.
