Index Bolts Index Plungers Compact with hexagon collar and locking with T-Handle 1

Index Bolts Index Plungers Compact with hexagon collar and locking with T-Handle 2

Index Bolts Index Plungers Compact with hexagon collar and locking with T-Handle 3

Index Bolts Index Plungers Compact with hexagon collar and locking with T-Handle 4

Index Bolts Index Plungers Compact with hexagon collar and locking with T-Handle

--Index bolts are used for indexing purposes.

--Application limited for cases in which no precise positioning is needed. The high stroke of the pin enables for a variety of applications, e.g. as door bolt.

--Simple version in compact design.

--Plastic cover for grip allows better handling.

--Simple handling, e.g. when using safety gloves, with higher pull release.

--Types with / without lock have the same building height.

--Due to a thread recess the index plungers can be completely screwed in.

--Indexing bolt: stainless steel chemical nickel plated

--T-handle: polyamide black, not demountable

Inquiry

Write a Review

Product Details

index bolts 5

index bolts 6

index bolts 7

Product Description

--These hand retractable pistons have a resting position in which the piston can remain in the retracted position.

--A new locking position cannot be adjusted until the latch has been released manually.

--Locking bolts are used to prevent a change in the locking position by side forces.

--Size: M6, M8, M10, M12, M16

--Piston body made of stainless steel/galvanised steel.

Index bolt for indexing purposes.

body: blackened free cutting steel; stainless steel 303 (1.4305);

locking pin: hardened steel; nickel-plated stainless steel 1.4305;

plastic cap: thermoplastic, black, dull;

catch: blackened free cutting steel; dry powdered metal 316

by turning the index bolt 180° the locking pin will be pulled-in and secured by a notched catch (when locking pin must not project);

Product Application

ap 1 (20)

ap 2 (20)
